Solar & UV film
Meridian Series
Sunlight, on your terms.
A spectrally-selective nano-ceramic film engineered for equatorial sun. Meridian blocks 100% of UV to 420nm and up to 99.2% of infrared heat at 1400nm, in three tints from near-clear to deep shade, so every window in the house gets the right balance of daylight and cool.
Bedrooms and mixed-exposure windows. Meaningful heat and glare reduction in rooms that still feel naturally lit.
The everyday balance most homes choose.
- Visible Light TransmissionVLT
- 33.5%
- Ultraviolet Rejection (to 420nm)UVR
- 100.0%
- Infrared Rejection (at 1400nm)IRR
- 98.5%
- Total Solar Energy RejectionTSER
- 57.7%
- Solar Heat Gain CoefficientSHGC
- 42.3%
- Selective Infrared RejectionSIRR
- 90.3%
Every tier blocks 100% of UV to 420nm; the tint you choose only decides daylight and heat. Not sure which? The on-site demo settles it in minutes, window by window.
Full specifications
| Specification | Meridian 65 | Meridian 35 | Meridian 15 |
|---|---|---|---|
| Visible Light TransmissionVLT | 66.3% | 33.5% | 16.6% |
| Ultraviolet Rejection (to 420nm)UVR | 100.0% | 100.0% | 100.0% |
| Infrared Rejection (at 1400nm)IRR | 99.2% | 98.5% | 97.6% |
| Total Solar Energy RejectionTSER | 45.4% | 57.7% | 64.4% |
| Solar Heat Gain CoefficientSHGC | 54.6% | 42.3% | 35.6% |
| Selective Infrared RejectionSIRR | 91.1% | 90.3% | 90.0% |
| Warranty | 12 years | 12 years | 12 years |
UVR measured to 420nm. IRR measured at 1400nm; SIRR averaged across 780–2500nm. Bring this table to any competing quote.
See it on your own glass
Free on-site demo: samples, heat lamp, UV meter and an exact quote.
